Features
Applicable for pure off grid / backup power / self-consumption
PV input voltage range: 80Vdc-500Vdc
PV input current up to 32A
Supports battery mode & non battery mode
Battery & PV reverse polarity protection
Dual pure sine wave output
Supports single-phase or three-phase parallel operation (up to 16 units)
Sleep mode triggered by low power output or low battery voltage
Independent BMS communication interface
Isolated RS485 interface:Connects with Bluetooth, WiFi, 4G, etc.
Optional 320 x 480 high-resolution color LCD screen or monochrome screen
Historical data recording function, storage capacity of 25000 records
Comprehensive electronic protection ensures safer and more stable operation
IP20 enclosure design with anti-dust kit
Specification
|
Model
|
KR6042-1250P20C
|
|
Utility input
|
|
Utility Input Voltage
|
176VAC to 264VAC (Default), 90VAC to 285VAC (Configurable)
|
|
Utility Input Frequency
|
45Hz to 65Hz
|
|
Maximum Utility Charging Current
|
100A
|
|
Switch Response Time
|
Switch Response Time – Inverter to Utility: 10ms
Switch Response Time – Utility to Inverter (when the load power is higher than 100W): 20ms
|
|
Inverter output
|
|
Inverter Rated Power (@30℃)
|
6000W
|
|
3-second Transient Surge Output Power
|
12000W
|
|
Inverter Output Voltage
|
220/230VAC±3%
|
|
Inverter Frequency
|
50/60Hz±0.2%
|
|
Output Voltage Waveform
|
Pure sine wave
|
|
Load Power Factor
|
0.2–1(VA ≤ Rated output power)
|
|
THDu (Total Harmonic Voltage Distortion)
|
≤3% (48V resistive load)
|
|
Maximum Load Efficiency
|
0.92
|
|
Maximum Inverter Efficiency
|
0.94
|
|
Maximum Main Load
|
6000W
|
|
Maximum Second Load
|
6000W
|
|
Main Output Cut-Off Voltage
|
Equal to “UVW (Under Voltage Warning Voltage)”
|
|
Second Output Cut-Off Voltage
|
Equal to “LVD (Low Voltage Disconnect Voltage)”
|
|
Dual Output Recovery Voltage
|
Equal to “LVR (Low Voltage Reconnect Voltage)”
|
|
Solar controller
|
|
PV Maximum Open-circuit Voltage
|
500V (At minimum operating environment temperature);
440V (At 25℃)
|
|
MPPT Voltage Range
|
85V to 450V
|
|
Number of MPPTs
|
2
|
|
PV Maximum Input Current
|
Two ways, 2x16A
|
|
PV Maximum Short-circuit Current
|
Two ways, 2x18A
|
|
PV Maximum Input Power
|
8000W
|
|
PV Maximum Charging Current
|
120A
|
|
MPPT Maximum efficiency
|
≥99.5%
|
|
Battery
|
|
Battery Rated Voltage
|
48VDC
|
|
Battery Work Voltage Range
|
40.8VDC to 64.0VDC
|
|
Battery Maximum Charging Current
|
120A
|
|
Others
|
|
No-load Losses
|
≤1.1A
|
|
Test condition: Utility, PV and Load are disconnected, AC output is ON, fan stops, @48V input
|
|
Standby Current
|
≤0.8A
|
|
Test condition: Utility, PV and Load are disconnected, AC output is OFF, fan stops, @48V input
|
|
Communication with BMS
|
RS485
|
|
Communication with Portal
|
RS485
|
|
Parallel Function
|
Yes, 12 units in standard, 16 units at most
|
|
Work Temperature Range
|
-20℃ to +50℃ (When the environment temperature exceeds 30℃, the actual output power is reduced appropriately)
|
|
Storage Temperature Range
|
-25℃ to +60℃
|
|
Enclosure
|
IP20 (With ANTI-DUST KIT)
|
|
Relative Humidity
|
< 95% (N.C.)
|
|
Altitude
|
<4000M (If the altitude exceeds 2000 meters, the actual output power is reduced appropriately)
|
|
Certifications and Standards
|
IEC 62109-1,IEC 62109-2,IEC 61683
|
|
Mechanical parameters
|
|
Dimension (Length x Width x Height)
|
590mm × 300mm × 165mm
|
|
Mounting size (Length x Width)
|
568mm × 245mm
|
|
Mounting hole size
|
Φ9mm/Φ10mm
|
|
Net Weight
|
15Kg
|
